Introduction to CFD Chapter 2: Meshing Foundations

This chapter introduces meshing as a numerical modeling activity rather than a geometric one. The purpose of the mesh, common meshing strategies, and practical quality metrics are summarized without reference to software-specific procedures. Emphasis is placed on understanding why different mesh types and controls exist, when they should be used, and how mesh quality directly affects accuracy, stability, and physical fidelity in CFD simulations.



What the Mesh Really Is

In CFD, the mesh is:

  • The numerical representation of the physical domain

  • The structure on which conservation laws are enforced

  • A key part of the mathematical model itself

CFD solvers:

  • Do not “see” CAD

  • Do not “see” smooth surfaces

  • Only see cells, faces, and connectivity

As a result:

A bad mesh cannot be fixed by a good solver.


Purpose of the Mesh

A good mesh must balance three competing goals:

  1. Accuracy

    • Resolve gradients where physics demands it

    • Near walls, interfaces, shocks, and separation

  2. Efficiency

    • Use fine cells only where needed

    • Keep cell count manageable

  3. Numerical robustness

    • Avoid pathological cell shapes

    • Ensure stable convergence

Every meshing decision is a compromise between these three.


Where Mesh Refinement Actually Matters

Refinement is physically justified in regions with:

  • High velocity or pressure gradients

  • Boundary layers

  • Curvature or small geometric features

  • Flow separation or recirculation

  • Heat transfer or species gradients

Uniform refinement everywhere is numerically expensive and physically meaningless.


Mesh Topology: The Big Picture

Unstructured vs Structured Thinking

  • Unstructured meshes
    Flexible, robust, geometry-friendly
    Higher numerical diffusion

  • Structured / semi-structured meshes
    Aligned with flow, lower numerical error
    Require geometric discipline

Modern CFD uses hybrid meshes by default.


Core Mesh Element Types (When to Use What)

Tetrahedra

  • Excellent for complex geometry

  • Automatic and robust

  • Higher numerical diffusion

  • Not ideal near walls unless combined with inflation

Use when: geometry complexity dominates.

Prisms / Wedges (Inflation Layers)

  • High aspect-ratio cells near walls

  • Resolve boundary-layer gradients

  • Essential for turbulence and heat transfer

Use whenever walls matter (which is almost always).

Hexahedra

  • Best numerical accuracy per cell

  • Low numerical diffusion

  • Aligned with flow direction

Use when geometry allows it, especially in ducts and channels.

Hybrid Meshes

  • Tets in the core

  • Prisms near walls

  • Hex where possible

This is the industrial default.


Patch Conforming vs Patch Independent (Conceptual)

Patch Conforming

  • Mesh follows CAD surfaces exactly

  • Preserves geometric detail

  • Requires clean geometry

Good for: high-quality CAD, when small features matter.

Patch Independent

  • Mesh ignores small geometric details

  • Geometry is approximated within tolerance

  • More robust for dirty CAD

Good for: early design, scanned geometry, complex assemblies


Hex Meshing Strategies

Sweep Meshing

  • Extrudes a 2D mesh through a volume

  • Requires topological similarity

  • Produces high-quality hex/wedge cells

Ideal for: pipes, channels, turbomachinery passages.

Multizone Meshing

  • Automatically decomposes geometry

  • Produces mostly hex meshes

  • Less control than manual blocking

Good compromise between quality and automation.


Inflation Layers: Why They Matter

Near walls:

  • Gradients scale with wall distance

  • Turbulence models assume proper wall-normal resolution

Inflation layers:

  • Provide controlled growth away from the wall

  • Maintain orthogonality

  • Reduce numerical stiffness

Without inflation:

Wall-bounded CFD results are rarely trustworthy.


Mesh Quality Metrics (The Real Cheat Sheet)

These metrics matter more than cell count.

Skewness

  • Measures deviation from ideal cell shape

  • High skewness → solver instability

Rule of thumb:
Low is good. Avoid extreme values near walls and interfaces.

Orthogonality

  • Measures alignment of face normals and cell centers

  • Poor orthogonality increases discretization error

Critical for: pressure–velocity coupling.

Aspect Ratio

  • Ratio of longest to shortest cell dimension

  • High aspect ratio acceptable only in boundary layers

Bad in the core, good near walls (when intentional).

Smoothness (Growth Rate)

  • Controls how fast cell size changes

  • Abrupt changes harm convergence

Gradual transitions improve solver robustness.


Mesh Quality vs Mesh Density

More cells ≠ better solution.

A coarser but well-shaped mesh often outperforms:

  • A very fine mesh with bad skewness

  • A mesh with poor wall resolution

Mesh refinement should always be physics-driven, not guilt-driven.


Meshing as Part of the CFD Loop

Mesh generation is not a one-shot step.

Typical workflow:

  1. Generate baseline mesh

  2. Run preliminary solution

  3. Inspect gradients and flow features

  4. Refine selectively

  5. Re-run and compare

Mesh independence is a process, not a checkbox.


Engineering Intuition

  • The mesh is part of the numerical model

  • Boundary layers deserve special treatment

  • Hex cells are gold, but not always feasible

  • Inflation is non-negotiable for wall physics

  • Quality beats quantity

  • A solver cannot fix a bad mesh


Study Priorities

If short on time, remember:

  1. Where refinement matters physically

  2. Why inflation layers exist

  3. Patch conforming vs independent

  4. Hybrid meshing philosophy

  5. Skewness, orthogonality, growth rate


Key Takeaways

  • Meshing is a modeling decision, not a technical step.

  • The solver only sees cells and faces.

  • Hybrid meshes are the industrial standard.

  • Boundary layers require structured resolution.

  • Mesh quality controls accuracy and stability.

  • Good CFD starts with good meshing judgment.
